Vibrating cup sample grinder IVCh-1
Purpose:
The grinder is designed for mechanical grinding of samples (dry and in suspension) of brittle materials of varying hardness and strength in preparation for chemical and X-ray spectral analysis.
Characteristic features:
A desktop device for one headset with small dimensions and lower installation power.
Possibility of connection to a 220V or 380V network (depending on the control panel).
sales@mtspb.com
Listing details
Additional information:
Number of bowls, pcs. 1
Feature of the initial material, mm, no more than up to 4
Weight of the sample to be ground in one bowl, g, no more than 50
Feature of the finished product (depends on the time of grinding), µm up to -50
Amplitude of oscillations of the working element, mm, no more than 4
Frequency of oscillations of the working element, Hz, no less than 23.4
Drive power, kW 0.37
Overall dimensions, mm, no more than
Length 570
Width 340
Height 420
Weight, kg 52
